SIRIO Gain-Master (1/2 Wave) 25-30MHz - CB & 10m Base Antenna (New Upgrade Version)
Product Code: MASTER-HALF
Rating: Be the first to write a review
Brand: Sirio
Product Condition: New
(Notify me when product is back in stock)
SIRIO Gain-Master (1/2 Wave) 25-30MHz - CB & 10m Base Antenna (New Upgrade Version)
Great performance from this 1/2 wave vertical that comes in at 5560mm approx. 18ft in length, and won't scare the neighbours unduly! Perfect for CB or the 10m amateur band
Key Features/Specifications:
Base station antenna, Omnidirectional
1/2 wave center fed vertical dipole
Low radiation angle for excellent DX
Fiberglass 3 section composite tube
Electrical Data:
Type: 1/2wave center fed vertical dipole
Frequency range: tunable from 27.2 to 30 MHz
Gain: 0 dBd, 2.15 dBi
Bandwidth 1800 KHz @ 27.2 MHz
Max. power: 500 Watts (CW) continuous
Connector: UHF-female, PTFE insulator & gold plated central pin
Mechanical Data:
Materials: Whip made of white fiberglass three section composite tube, radiator made of copper wire and low loss coax cable, stainless steel hardware, anodized AW6060 aluminium, UV stabilized thermoplastic
Height (approx.): 5560 mm / 18.2 feet
Weight (approx.): 2600 gr / 5.7 lb
Mounting mast: Ø 35-54 mm / Ø 1.4-2.1 in
Boxed Size: 6 feet
Great performance from this 1/2 wave vertical that comes in at 5560mm approx. 18ft in length, and won't scare the neighbours unduly! Perfect for CB or the 10m amateur band
Key Features/Specifications:
Base station antenna, Omnidirectional
1/2 wave center fed vertical dipole
Low radiation angle for excellent DX
Fiberglass 3 section composite tube
Electrical Data:
Type: 1/2wave center fed vertical dipole
Frequency range: tunable from 27.2 to 30 MHz
Gain: 0 dBd, 2.15 dBi
Bandwidth 1800 KHz @ 27.2 MHz
Max. power: 500 Watts (CW) continuous
Connector: UHF-female, PTFE insulator & gold plated central pin
Mechanical Data:
Materials: Whip made of white fiberglass three section composite tube, radiator made of copper wire and low loss coax cable, stainless steel hardware, anodized AW6060 aluminium, UV stabilized thermoplastic
Height (approx.): 5560 mm / 18.2 feet
Weight (approx.): 2600 gr / 5.7 lb
Mounting mast: Ø 35-54 mm / Ø 1.4-2.1 in
Boxed Size: 6 feet
