Sirio SY-3 27MHz 3 Element YAGI CB Antenna (26.5-30 MHz Tunable)
Product Code: SIR-3ELE
Rating: Be the first to write a review
Brand: Sirio
Product Condition: New
Sirio SY-3 27MHz 3 Element YAGI CB Antenna (26.5-30 MHz Tunable)
The Sirio SY 27-3 is a high quality, light weight, low priced 3 element beam that covers 26.5 to 30MHz. but It can also be easily made to work on the 28 MHz Amateur Band.
They are incredible value for money and with good band conditions, you can work the world with ease and put out a big signal with these high gain antennas. It's Sirio build quality too, for a very happy and long life
Features/Specification
CB Base station antennas
Directional, High-gain
Horizontal polarization
Factory tuned at mid-band
High power handling capability
Elements equipped whit waterproof jointing sleeve
Made of aluminium alloy 6063 T-832
SY element Yagi antenna
Frequency range: 26.1-27.7 MHz @ SWR ≤ 2
Impedance: 50 ohm unbalanced
Radiation (H-plane): directional
Polarization: linear horizontal
Gain: 8.5 dBd, 10.65 dBi
Bandwidth @ SWR ≤ 2 ≥ 1800 KHz (160 channel)
SWR @ res. freq.: ≤ 1.2
Max. power: 1000 Watts (CW) continuous 3000 Watts (CW) short time
Feed system / position: Gamma match / center
Connector: SO239 socket
Materials: Aluminium, Steel, Nylon
Wind load: 86 N at 150 Km/h
Wind resistance: 120 Km/h
Wind surface: 0.07 m²
Dimensions (approx.): 5740 x 2710 x 100 mm
Boom length / diameter: 2710 mm / 33 mm
Max. element length (approx.): 5740 mm
Turning radius (approx.): 3200 mm
Weight (approx.): 4700 g
Mounting mast: 35-50 mm
The Sirio SY 27-3 is a high quality, light weight, low priced 3 element beam that covers 26.5 to 30MHz. but It can also be easily made to work on the 28 MHz Amateur Band.
They are incredible value for money and with good band conditions, you can work the world with ease and put out a big signal with these high gain antennas. It's Sirio build quality too, for a very happy and long life
Features/Specification
CB Base station antennas
Directional, High-gain
Horizontal polarization
Factory tuned at mid-band
High power handling capability
Elements equipped whit waterproof jointing sleeve
Made of aluminium alloy 6063 T-832
SY element Yagi antenna
Frequency range: 26.1-27.7 MHz @ SWR ≤ 2
Impedance: 50 ohm unbalanced
Radiation (H-plane): directional
Polarization: linear horizontal
Gain: 8.5 dBd, 10.65 dBi
Bandwidth @ SWR ≤ 2 ≥ 1800 KHz (160 channel)
SWR @ res. freq.: ≤ 1.2
Max. power: 1000 Watts (CW) continuous 3000 Watts (CW) short time
Feed system / position: Gamma match / center
Connector: SO239 socket
Materials: Aluminium, Steel, Nylon
Wind load: 86 N at 150 Km/h
Wind resistance: 120 Km/h
Wind surface: 0.07 m²
Dimensions (approx.): 5740 x 2710 x 100 mm
Boom length / diameter: 2710 mm / 33 mm
Max. element length (approx.): 5740 mm
Turning radius (approx.): 3200 mm
Weight (approx.): 4700 g
Mounting mast: 35-50 mm
